Literature



SQRTM Enables Net-Shape Parts - Inside Manufacturing

New out-of-autoclave process combines resin transfer molding with prepregs for complex helicopter part prototype.

ISO 9001:2008 and AS9100C Certification

Radius has been certified ISO 9001:2008 and AS9100C for our Quality Management System.

FEB 2016

Reducing manufacturing cost via RTM - CompositesWorld

Airbus Bremen aims to eliminate dozens of prepreg components and assembly operations with a unitized multispar composite flap molded in a one-shot process.

FEB 2016

GE Aviation, Batesville, MS, US

With a supply chain busy making commercial jet engines like the GE90, GEnx, LEAP and GE9X, GE Aviation has invested heavily in its composites capabilities in Batesville.


JAN 2016

Radius Featured in the January/Feburary 2016 SAMPE Journal

The SAMPE Journal for January/Feburary 2016 features Radius' SQRTM process used by Sonaca S.A. (Gosselies, Belgium) to produce high quality resin infused wing sections, nose, trailing edge and skin panels. The cover features photos of some of these parts.


NOV 2015

Case Study: Reducing manufacturing cost via RTM

Airbus Bremen aims to replace dozens of prepreg components and assembly operations with a unitized multispar composite flap molded in a one-shot process.


FEB 2015

Analysing process-induced deformation and stresses using a simulated manufacturing process for composite multispar flaps

  • Christian Brauner Faserinstitut Bremen e.V., Am Biologischen Garten 2, 28359 Bremen, Germany
  • Stefan Bauer Airbus, Bremen, Germany
  • Axel S Herrmann Faserinstitut Bremen e.V., Am Biologischen Garten 2, 28359 Bremen, Germany

Although composite materials have numerous advantages, some disadvantages, including high manufacturing costs, are relevant. In particular, if the material is applied to large structural components, such as the wings, flaps or fuselage of an airplane, efficient manufacturing processes are required to generate products that are both high quality and cost effective. Therefore, monolithic designs often become integral due to the lower overall part count and simplified designs (e.g. reducing the number of joints and fasteners significantly). For highly integrated monolithic structures, developing a robust manufacturing process to produce high quality structures is a major challenge. An integral structure must conform to the tolerance requirements because those requirements may change. Process-induced deformations may be an important risk factor for these types of structures in the context of the required tolerances, manufacturing costs and process time. Manufacturing process simulations are essential when predicting distortion and residual stresses. This study presents a simulation method for analysing process-induced deformations on the structure of a composite multispar flap. The warpage depends on the thermal expansion and shrinkage of the resin. In this study, a sequentially coupled thermo-mechanical analysis of the process will be used to analyse temperature distribution, curing evolution, distortion and residual stresses of 7.5?m long composite part.
